Technical metadataΒΆ

The Technical metadata tab (keyboard shortcut Alt+T) allows you to edit ‘technical’ information about your photographs, such as the date & time they were taken and the lens that was used (if your camera has interchangable lenses). You can also set the image orientation, which is useful if your camera doesn’t set it correctly. (This often happens to me when taking pictures looking straight up or down.) I also like to set the time zone of all my pictures, especially when I’m holidaying in another country.

../_images/screenshot_50.png

The GUI shows three date/time entries - taken, digitised and modified. These are often the same, and are linked by the link ... check boxes. These allow you to change all three when you change the taken date/time.

You may wish to unlink the three entries and adjust the dates or times separately. For example, you could use the modified entry to note when you have edited the metadata with Photini. If you scan some old photographs you should set the taken entry to when the photographs were taken and the digitised entry to when you scanned them.

The date can be picked from a calendar widget that pops up when you click on the down arrow in a date/time entry. Clicking on any of the numbers allows them to be adjusted with your keyboard up & down arrow keys. You can also double click on any of the numbers to select it and type a new value in directly. Selecting all the numbers, e.g. with Ctrl+A, allows them to be deleted which removes the date & time metadata from the photograph(s).

../_images/screenshot_51.png

To the right of each date/time is a widget to adjust the time zone. The time a photograph was taken is assumed to be “local time”. The time zone records how many hours & minutes offset from UTC (or GMT) the local time zone was when the photograph was taken, digitised or modified.

../_images/screenshot_53.png

The Adjust times field allows a constant offset to be applied to the time stamps of several pictures at once. This can be useful if you are in a different time zone to your camera’s setting or you forgot to set your camera’s clock before a day’s shooting! Set the required offset hours, minutes & seconds, then use the + or - button to add or subtract that amount from each selected picture’s timestamp.

../_images/screenshot_53a.png

You can also offset the time zone. In this example my camera clock was set to British Summer Time (+01:00) but records timestamps without zone information. I was on holiday in mainland Europe (+02:00) so I need to add 1 hour to each timestamp and 2 hours to the time zone. The Adjust times values are stored in Photini’s configuration file, so each day’s photos can be given the same offset with just one button click.

../_images/screenshot_52.png

Below each date/time is a slider that allows you to set the precision. At its maximum value the time is shown to a precision of 1 millisecond. Cameras that can take more than one photograph per second need this precision! Moving the slider to the left removes parts of the date & time. For example, you may know the date when an old photograph was taken but not the time. You might only know the year it was taken in. Setting the precision allows you to record this uncertainty.

The Orientation value sets the required rotation or reflection to display the image. Note that this does not actually transform the image data. Image display programs should rotate or reflect the image according to the orientation metadata, but not all of them do.

The Lens model dropdown list allows you to change the lens specification stored in the image metadata. This should usually be left blank for cameras with non-removable lenses, but may be useful if you have an SLR that you use with lenses that its electronics doesn’t recognise.

Lens details already in a photograph’s metadata are automatically added to the list when the photograph is loaded. If your camera doesn’t record the details of some lenses you can add them by selecting <define new lens> from the dropdown list.

../_images/screenshot_54.png

This brings up a dialog box for you to enter the lens details. Type all the relevant information into the appropriate boxes, leaving blank any information you don’t have such as the serial number. Only the Model name and Minimum focal length are required.

../_images/screenshot_55.png

The data you enter is stored in the Photini configuration file so you can easily apply it to images in future by selecting the lens you have defined from the dropdown list. To remove a lens from the list right-click on it to bring up its context menu. This includes options to delete any lens but the one currently in use.

../_images/screenshot_56.png

Adjusting the lens metadata is useful if, like me, you use your camera with 3rd party lenses and/or telescopes via a T-thread adaptor. My adaptor identifies itself to the camera as a 50mm f/1.8 lens. Here I’ve used it with my 500mm mirror lens to take some pictures of the moon.

../_images/screenshot_57.png

When I set the lens model via the drop down list Photini offers the option to adjust the focal length and aperture used for each image, if the current values are inconsistent with the new lens. In this case I definitely do want to update these parameters so I click on Yes.

../_images/screenshot_58.png

Comments or questions? Please subscribe to the Photini mailing list https://groups.google.com/forum/#!forum/photini and let us know.
